矿用电源检验用交流电压阶跃试验装置的研究

基金项目:

煤炭科学技术研究院科技发展基金项目（2014CX22）

煤炭科学技术研究院检测分院科技发展基金项目（2015JC07）

详细信息

Research of AC voltage step experiment instrument for mine-used power supply testing

1.
Test Branch, China Coal Research Institute, Beijing 100013, China
2.
State Key Laboratory of Coal Mining and Clean Utilization, Beijing 100013, China

摘要:
介绍了一种矿用电源检验用交流电压阶跃试验装置。该装置以触摸屏作为指令输入和电压指示窗口，以Modbus-RTU作为通信方式，用单片机控制交流固态继电器实现不同交流电压之间的阶跃功能。127 V电压等级带载试验结果表明，该装置能够安全、可靠地进行电压阶跃试验，最大带载电流不低于5 A，阶跃时间不超过50 ms。
- 矿用电源 /
- 源效应试验 /
- 电压阶跃试验 /
- 触摸屏 /
- 交流固态继电器
Abstract:
An AC voltage step experiment instrument for mine-used power supply testing was introduced. The instrument uses touch screen as window of command input and voltage indicator, Modbus-RTU as communication protocol, and single chip microcomputer to control AC solid-state relay to realize step among different voltages. Load test result shows that under 127 V voltage level, the instrument can do step voltage experiment safely and reliably, with the max load current of more than 5 A and step time of less than 50 ms.
- mine-used power supply /
- source effect experiment /
- voltage step experiment /
- touch screen /
- AC solid-state relay
