柱面弯曲对矿用可穿戴半模衬底集成空腔天线性能的影响

刘逢雪, 崔洁, 孙红, 魏明生

刘逢雪，崔洁，孙红，等.柱面弯曲对矿用可穿戴半模衬底集成空腔天线性能的影响［J］.工矿自动化，2019,45（3）：95-98.. DOI: 10.13272/j.issn.1671-251x.17378
引用本文: 刘逢雪，崔洁，孙红，等.柱面弯曲对矿用可穿戴半模衬底集成空腔天线性能的影响［J］.工矿自动化，2019,45（3）：95-98.. DOI: 10.13272/j.issn.1671-251x.17378
shu
LIU Fengxue, CUI Jie, SUN Hong, WEI Mingsheng. Influence of cylindrical bending on performance of mine-used wearable half-mode substrate-integrated cavity antenna[J]. Journal of Mine Automation, 2019, 45(3): 95-98. DOI: 10.13272/j.issn.1671-251x.17378
Citation: LIU Fengxue, CUI Jie, SUN Hong, WEI Mingsheng. Influence of cylindrical bending on performance of mine-used wearable half-mode substrate-integrated cavity antenna[J]. Journal of Mine Automation, 2019, 45(3): 95-98. DOI: 10.13272/j.issn.1671-251x.17378
shu

柱面弯曲对矿用可穿戴半模衬底集成空腔天线性能的影响

  • 1.

    江苏师范大学 物理与电子工程学院， 江苏 徐州221116

  • 2.

    东南大学 信息科学与工程学院， 江苏 南京210096

  • 3.

    江苏建筑职业技术学院 交通工程学院， 江苏 徐州221116

基金项目:

江苏省高等学校自然科学研究面上项目（18KJB510014）

徐州市科技项目（KC16SG268）

详细信息

  • 中图分类号: TD655.3

Influence of cylindrical bending on performance of mine-used wearable half-mode substrate-integrated cavity antenna

  • 1.

    School of Physics and Electronic Engineering, Jiangsu Normal University, Xuzhou 221116, China

  • 2.

    School of Information Science and Engineering, Southeast University, Nanjing 210096, China

  • 3.

    School of Transportation Engineering, Jiangsu Vocational Institute of Architectural Technology, Xuzhou 221116, China

摘要

    摘要
  • 摘要: 对矿用可穿戴半模衬底集成空腔天线在柱面弯曲情况下的频率特性、阻抗匹配及辐射特性进行了仿真分析，结果表明：天线柱面弯曲导致谐振频率升高，但-10 dB相对带宽基本不变；当辐射开口发生弯曲时，天线阻抗匹配随着弯曲程度增大而逐渐变差；天线柱面弯曲造成正向辐射增益降低、背向辐射增益升高。因此，针对天线在柱面弯曲情况下的应用，应适当增大天线空腔尺寸和导电底面的长度或宽度，并在选择天线放置方向时应保持辐射开口不弯曲。
    Abstract: Frequency characteristics, impedance matching and radiation characteristics of mine-used wearable half-mode substrate-integrated cavity antenna under cylindrical bending condition were simulated. The simulation results show that cylindrical bending of the antenna leads to an increase of resonance frequency, but the relative bandwidth of -10 dB is basically unchanged. When radiation aperture is bent, impedance matching of the antenna becomes worse as curvature increases. Cylindrical bending of the antenna results in decrease of forward radiation gain and increase of backward radiation gain. Therefore, in view of application of the antenna under cylindrical bending, cavity size and length or width of conductive bottom should be appropriately increased, and radiation aperture should be kept unbent when selecting placement direction of the antenna.
