开关磁阻电动机驱动系统人机界面设计

基金项目:

太原市科技局大学生创新创业专项（110148032）

详细信息

Design of human machine interface of switched reluctance drive system

1.
College of Electrical and Power Engineering, Taiyuan University of Technology, Taiyuan 030024, China
2.
Shanxi Key Laboratory of Coal Mining Equipment and Safety Control, Taiyuan 030024, China

摘要: 针对现有的开关磁阻电动机驱动系统缺乏友好的人机界面来显示系统运行状态、设置给定参数的问题, 提出了一种基于简化的ModBus通信协议的开关磁阻电动机驱动系统人机界面的设计方案。给出了开关磁阻电动机驱动系统总体结构，详细介绍了人机界面中串行通信电路及通信程序的设计。调试结果表明，该人机界面运行稳定，实现了开关磁阻电动机驱动系统的友好显示和在线参数修改功能。
- 开关磁阻电动机驱动 /
- 人机界面 /
- ModBus通信协议 /
- 串行通信
Abstract: In view of problem that current switched reluctance drive systems are lack of friendly human machine interface to display running state of the system and set given parameters, the paper proposed a design scheme of human machine interface of switched reluctance drive system based on simplified ModBus communication protocol. It gave general structure of the switched reluctance drive system, and introduced design of serial communication circuit and communication program in the human machine interface. Debugging result shows that the human machine interface runs stably and realizes functions of friendly display and online parameters modification for the switched reluctance drive system.
- switched reluctance drive /
- human machine interface /
- ModBus communication protocol /
- serial communicatio
