煤矸光电分选系统设计

王卫东, 张晨, 马中良, 曹春晓, 王彤彤, 张璐琪, 任春醒, 梁静

王卫东,张晨,马中良,等.煤矸光电分选系统设计[J].工矿自动化,2013, 39(12):5-8.. DOI: 10.7526/j.issn.1671-251X.2013.12.002
引用本文: 王卫东,张晨,马中良,等.煤矸光电分选系统设计[J].工矿自动化,2013, 39(12):5-8.. DOI: 10.7526/j.issn.1671-251X.2013.12.002
WANG Wei-dong, ZHANG Chen, MA Zhong-liang, CAO Chun-xiao, WANG Tong-tong, ZHANG Lu-qi, REN Chun-xing, LIANG Jing. Design of photometric separation system for coal and gangue[J]. Journal of Mine Automation, 2013, 39(12): 5-8. DOI: 10.7526/j.issn.1671-251X.2013.12.002
Citation: WANG Wei-dong, ZHANG Chen, MA Zhong-liang, CAO Chun-xiao, WANG Tong-tong, ZHANG Lu-qi, REN Chun-xing, LIANG Jing. Design of photometric separation system for coal and gangue[J]. Journal of Mine Automation, 2013, 39(12): 5-8. DOI: 10.7526/j.issn.1671-251X.2013.12.002

煤矸光电分选系统设计

基金项目:

国家自然科学基金资助项目(51204190,51274208)

中央高校基本科研业务费专项资金资助项目(2009HR001)

详细信息
  • 中图分类号: TD92

Design of photometric separation system for coal and gangue

  • 摘要: 针对煤矸石井下分选回填及综合利用的需求,提出了一种基于激光三维扫描与动态称重的煤矸光电分选系统的设计方案。首先由称重部分对被测物称重,并从所拍摄的每幅被测物图像中提取激光线,计算每幅图像中被测物光切面的面积,然后根据被测物的体积和质量,按照识别算法对煤矸石进行识别,并根据识别结果向煤矸分选驱动机构发送分选信号,从而实现煤与矸石的在线实时分选。测试结果表明,该系统配合相应的执行机构能够准确地识别出煤和矸石,识别率为90%。
    Abstract: In view of requirements of underground separation and backfilling and utilization for coal and gangue, the paper proposed a design scheme of photometric separation system for coal and gangue based on laser 3D scanning and dynamic weighing. Firstly, the system uses weighing unit to weigh measured object, and extracts laser line from each image of the measured object to calculate areas of optical section of the measured object. Then the system uses recognition algorithm to recognize coal and gangue according to volume and weight of the measured object, and sends separation signal to driving unit of separation for coal and gangue according to recognition result, so as to realize real-time online separation for coal and gangue. Test result shows that the system can recognize coal and gangue accurately combining with relative actuator and its recognition rate is 90%.
计量
  • 文章访问数:  82
  • HTML全文浏览量:  19
  • PDF下载量:  20
  • 被引次数: 0
出版历程
  • 刊出日期:  2013-12-09
