Design of universal automatic test platform for circuit board based on virtual instrument
-
摘要: 针对传统电路板测试系统的单一性和专用性问题，为满足不同电路板的自动测试需求，设计了一种基于虚拟仪器的电路板通用自动测试平台。该平台采用虚拟仪器测试技术、扫码技术、网络技术实现了不同类型电路板的自动测试，测试结果与电路板序列号绑定并自动保存到服务器数据库中，并可通过Web浏览方式查询电路板测试结果。测试结果表明，该平台可实现不同类型电路板的自动测试，在保证测试结果准确性的前提下，提高了电路板的测试精度和测试效率。Abstract: In view of problems of singleness and specificity of traditional circuit board test platform, in order to meet automatic testing requirements of different circuit boards, an universal automatic test platform for circuit board based on virtual instrument was designed. The platform achieves automated testing of different types of boards using virtual instrument testing technology, scan code technology and network technology. The test results are bound to serial number of the board and automatically saved to database of server, and the board test results can be queried via web browsing. The test results show that the platform can realize automatic test of different types of circuit boards, and improves test accuracy and efficiency under the premise of ensuring test accuracy of the circuit board.
-
-
