真空断路器真空度检测方法研究现状与展望

吴梦泽; 宋建成; 高云广; 陈姝姝

doi:10.13272/j.issn.1671-251x.2017120019

真空断路器真空度检测方法研究现状与展望

吴梦泽^{1, 2},
宋建成^{1, 2},
高云广^{1, 2},
陈姝姝^{1, 2}

1.
太原理工大学煤矿电气设备与智能控制山西省重点实验室，山西太原030024
2.
太原理工大学矿用智能电器技术国家地方联合工程实验室，山西太原030024

基金项目:

山西省科技重大专项项目（20131101029）

详细信息

中图分类号: TD611
计量
- 文章访问数: 105
- HTML全文浏览量: 13
- PDF下载量: 16
出版历程
- 刊出日期: 2018-06-09

Research status and prospect of vacuum degree detection methods for vacuum circuit breaker

WU Mengze^{1, 2},
SONG Jiancheng^{1, 2},
GAO Yunguang^{1, 2},
CHEN Shushu^{1, 2}

1.
Shanxi Key Laboratory of Mining Electrical Equipment and Intelligent Control, Taiyuan University of Technology, Taiyuan 030024, China
2.
National & Provincial Joint Engineering Laboratory of Mining Intelligent Electrical Apparatus Technology, Taiyuan University of Technology, Taiyuan 030024, China

摘要

摘要: 介绍了真空断路器真空度检测方法——观察法、工频耐压法、脉冲磁控放电法、屏蔽罩电位法等离线式检测方法和耦合电容法、局部放电法、旋转电场探头法、X射线法、内置传感器法等在线式检测方法的研究现状，分析了各方法的检测原理、特点和应用情况。指出真空度离线式检测方法中脉冲磁控放电法和工频耐压法因为成本低、检测简单和重复性好，成为目前应用最广泛的真空度检测方法，但定期停机检查真空度成为制约该类方法发展的最主要因素；真空度在线式检测方法可实时检测真空度，及时发现真空度的劣化，但存在精度较低、成本高、抗干扰能力和稳定性较差等问题，因此未得到广泛应用。提出提高真空度在线式检测方法精度和融合多种真空度检测方法是真空断路器真空度检测方法的发展趋势。
- 真空断路器 /
- 真空灭弧室 /
- 真空度 /
- 真空度检测方法
Abstract: Research status of vacuum degree detection methods for vacuum circuit breaker was introduced including off-line detection methods such as observation method, power frequency withstand voltage method, pulsed magnetron discharge method and shield potential method, and on-line detection methods such as coupling capacitance method, partial discharge method, rotary electric field probe method, X ray method and built-in sensor method. Though analyzing detection principle, characteristics and application of each method, it indicated that pulsed magnetron discharge method and power frequency withstand voltage method in off-line detection methods were the most widely applied because of low cost, simple detection and good repeatability, but regular stopping to check vacuum degree became the most important factor to restrict development of the off-line detection methods, and on-line detection methods could detect vacuum degree in real time and find deterioration of vacuum degree, but the methods were not widely applied because of low accuracy, high cost and poor anti-interference and stability. Development trends of vacuum degree detection method for vacuum circuit breaker were proposed, which were improving accuracy of on-line vacuum degree detection method and integrating multiple vacuum degree detection methods.
- vacuum circuit breaker /
- vacuum interrupter /
- vacuum degree /
- vacuum degree detection method
