一种新型井下自动上卸料装置

基金项目:

江苏省产学研联合创新资金前瞻性联合研究项目（BY2014028-04）

详细信息

A new type of underground automatic loading and unloading device

School of Mechatronic Engineering, China University of Mining and Technology, Xuzhou 221116, China

摘要: 针对井下喷浆支护过程中，混凝土干拌物进入搅拌机的过程因采用人工上料方式而导致效率低的问题，通过分析现有自动上卸料装置结构，提出了一种新型井下自动上卸料装置，重点介绍了该装置的结构设计。该装置采用履带行走机构，能够随搅拌机移动；采用闭合抓斗，减少了粉尘；自动进行上卸料工作，有利于提高支护效率。
- 喷浆支护 /
- 自动上卸料装置 /
- 自动上料 /
- 自动卸料
Abstract: For low efficiency caused by manually putting dry concrete material into pug mill during underground guniting support, a new type of automatic loading and unloading device was proposed by analyzing structures of existing automatic loading and unloading devices, and structure design of the device was introduced in details. The device uses caterpilar belt running gear to move following pug mill, adopts closed clam bucket to reduce dust, and loads and unloads concrete material automatically, so as to improve supporting efficiency.
- guniting support /
- automatic loading and unloading device /
- automatic loading /
- automatic unloading
