用于瓦斯抽放钻场的液压钻机牵引移动装置

详细信息

Dragging transport equipment for hydraulic drill used in gas drainage drill site

Cheji Coal Mine, Yongcheng Mining Branch of Henan Energy and Chemical Industry Group Co., Ltd., Yongcheng 476600, China

摘要: 针对目前瓦斯抽放钻场设备人力移运方式存在人员劳动强度大、效率低、安全性差等问题，介绍了一种液压钻机牵引移动装置的整体结构、液压系统及电控系统的设计方案。该装置采用模块化设计方法，利用钻机油泵提供的动力，通过液压油缸牵引钻场设备向目标地点移动，具有遥控功能。该装置在车集煤矿的应用表明其降低了人员劳动强度，提高了钻场设备移运效率和安全性，具有很高的经济和社会效益。
- 瓦斯抽放钻场 /
- 液压钻机 /
- 钻机移运 /
- 牵引移动
Abstract: For problems of large labor strength, low efficiency and poor security of device transport mode by manual labour in gas drainage drill site at present, design schemes of whole structure, control system and hydraulic system of a dragging transport equipment for hydraulic drill were introduced. The euipment, designed with modular method, can drag drill site devices towards destination through hydro-cylinder driven by pump of hydraulic drill. What is more, the equipment has remote control function. Application in Cheji Coal Mine shows that the equipment reduces labor strength and improves device transport efficiency and security, which has high economic and social benefits.
- gas drainage drill site /
- hydraulic drill /
- drill transport /
- dragging transport
