矿山高压多电平ANPC变频调速系统损耗分析

详细信息

Loss analysis of frequency-conversion speed-regulation system of mine high-voltage multilevel ANPC

1.
Department of Information Engineering, Jiangsu Polytechnic College of Agriculture and Forestry, Zhenjiang 212400, China
2.
School of Information and Electrical Engineering, China University of Minin

摘要: 以五电平有源中点箝位ANPC高压变频调速系统为研究对象，在介绍ANPC五电平拓扑数学模型和PWM调制方法的基础上，对系统开关损耗、电容损耗以及传导损耗进行了量化分析。分析结果表明，ANPC五电平拓扑虽然损耗构成种类更多，但其在开关损耗抑制方面优势显著，可使变频调速系统整体运行效率更高。
- 高压变频 /
- 有源中点箝位 /
- 五电平 /
- 损耗优化 /
- ANPC
Abstract: Taking frequency-conversion speed-regulation system of high-voltage five-level active neutral point clamped ANPC as a research object, switching loss, capacitance loss and transmission loss of the system were carried on quantitative analysis on the basis of introducing mathematical topology model of ANPC five-level and PWM modulation method. The analysis results show that although loss type of the ANPC five-level topology is more, but it has significant advantage in controlling switching loss, and can make the frequency-conversion speed-regulation system of motor have more efficient operation.
- high-voltage frequency-conversion /
- active neutral point clamped /
- five-level /
- loss optimization /
- ANPC
