能量回馈式电压型PWM整流器的研究

基金项目:

河南省科技攻关项目(082102210015)

详细信息

Research of Energy Feedback VSR

School of Electronic Information Engineering of Henan University of Science and Technology, Luoyang 471000, China

摘要: 针对二极管整流电路无法实现能量的双向流动问题,提出了一种能量回馈式电压型PWM整流器(VSR)的设计方案,在给出了三相VSR主电路拓扑结构及其一般数学模型的基础上,详细分析了能量回馈式VSR的控制原理,介绍了改进的SVPWM算法的实现,并在Matlab/Simulink中建立了仿真模型。仿真结果表明,该VSR稳定性好、动态响应速度快,实现了能量的双向流动。
- 电压型PWM整流器 /
- SVPWM /
- 能量回馈 /
- VSR
Abstract: In view of the problem that diode rectifying circuit ca't realize bidirectional flow of energy, the paper proposed a design scheme of energy feedback VSR. On the basis of topology of main circuit and mathematical model of three-phase VSR, it analyzed control principle of the energy feedback VSR in details, and introduced implementation of improved SVPWM algorithm. At last it built simulation model in Matlab/Simulink. The simulation result showed that the VSR has good stability and quick dynamic response speed and realizes bidirectional flow of energy.
- voltage PWM rectifier, SVPWM, energy feedback, VSR
