Profibus-DP单主站系统实时性研究

陈梅, 姚启云, 李鑫, 陈薇, 刘贞英

陈梅, 姚启云, 李鑫, 陈薇, 刘贞英. Profibus-DP单主站系统实时性研究[J]. 工矿自动化, 2011, 37(1): 64-67.
引用本文: 陈梅, 姚启云, 李鑫, 陈薇, 刘贞英. Profibus-DP单主站系统实时性研究[J]. 工矿自动化, 2011, 37(1): 64-67.
CHEN Mei, YAO Qi-yun, LI Xin, CHEN Wei, LIU Zhen-ying. Research of Real-time Performance of Profibus-DP Single Master-station System[J]. Journal of Mine Automation, 2011, 37(1): 64-67.
Citation: CHEN Mei, YAO Qi-yun, LI Xin, CHEN Wei, LIU Zhen-ying. Research of Real-time Performance of Profibus-DP Single Master-station System[J]. Journal of Mine Automation, 2011, 37(1): 64-67.

Profibus-DP单主站系统实时性研究

基金项目:

国家自然科学基金项目(61004082),安徽省高校优秀青年人才基金项目(2009SQR2014)

详细信息
  • 中图分类号: TD655

Research of Real-time Performance of Profibus-DP Single Master-station System

Funds:

国家自然科学基金项目(61004082),安徽省高校优秀青年人才基金项目(2009SQR2014)

  • 摘要: 分析了Profibus-DP协议数据链路层的运行机理,详细描述了构成Profibus-DP总线周期的时间参数,给出了报文循环时间、令牌目标轮转时间和系统反应时间这三个Profibus-DP系统实时性能指标的具体计算公式,并结合Profibus-DP单主站系统实例,通过测算系统反应时间分析了影响Profibus-DP单主站系统实时性的因素,最后提出可通过提高通信速率、减少从站数量、减少交换数据量来提高Profibus-DP单主站系统实时性。
    Abstract: The paper analyzed operating mechanism of data link layer of Profibus-DP protocol, described time parameters that compose Profibus-DP bus cycle in details, and gave concrete calculating formulas of real-time indexes of Profibus-DP system named message cycle time, token target rotation time and system reaction time. Combining an example of some Profibus-DP single master-station system, it analyzed factors which affect real-time performance of Profibus-DP single master-station system through calculating system reaction time, and finally proposed methods to improve real-time performance of Profibus-DP single master-station system, including improving communication speed and decreasing number of substations and changed data.
